Voltage

电压

Voltage rated:  AC208-240V 50/60HZ

额定电压： AC208-240V 50/60HZ

Working Temperature

工作温度

Max. Temperature: 1200℃( 1 hr)

**温度：1200℃ (1小时)

Continuous working temperature: ≤1100℃

持续工作温度：≤1100℃

Max. Heating/colling Rate: ≤20℃/S

升温速率：≤20℃/秒

Temperature Controller

控温方式

PID automatic control and auto-tune function.

模糊PID控制和自整定调节

30 programmable segments for precise thermal processing.

智能化30段可编程控制

Built-in protection for the over-heated and broken thermocouple.

超温和断偶报警功能

Length of heating zone

加热区长度

440mm

Length of constant zone

恒温区长度

200mm

Heating Elements

加热元件

Resistance wire, Fe-Cr-Al Alloy doped by Mo

电阻丝（掺钼铁铬铝合金）

Temperature Accuracy

控温精度

+/- 1℃

Processing tube

炉管

Φ50/60/80/100*1400mm(optional)

Φ50/60/80/100*1400mm(管径可选)

Two tube blocks are included for blocking heat radiation generated from tube center， must be fully inserted into the furnace chamber before heating in the correct position(quartz or ceramic optional).

两个管堵阻挡管中心产生的热辐射，必须在加热前塞进炉膛的正确位置(石英或氧化铝管堵可选)

Dimensions

尺寸

Furnace size :1500*380*620mm(L*W*H without tube & flange)

炉子尺寸：1500*380*620mm(长*宽*高 不含炉管和法兰)

Net Weight

净重

130kg

Vacuum Flange

真空法兰


KF25 quick clamp flange

两端为KF25快速卡箍法兰

Vacuum Pressure

真空压力

1pa can be achieved by mechanical pump

机械泵可达1pa

10^-4 pa can be reached by molecular pump

分子泵可达10^-4pa

Please click the picture below to order vacuum parts

点击下列图片订购真空部件

Warranty

质保

One year limited warranty with lifetime support  (Such consumable parts as tube, quartz block, and O-rings, etc. are NOT supported by the warranty)

一年质保终身支持（消耗品如炉管，石英管堵，O型圈等不在质保范围内）

Warning

注意事项

Small cracks may appear on the surface of the refractory ceramics over extended use. This is a normal occurrence and the cracks may be repaired with alumina coating.

在使用过程中炉膛表面可能出现细小裂纹。这是正常情况，裂纹可以用氧化铝涂层修复。

Compliance

认证

CE Certified

CE认证

The furnace is ready to pass TUV (UL61010) or CSA certification at extra cost.

付费可进行TUV(UL61010)或CSA认证

Operation instructions

操作指导

Click to download the operating manual

点击下载说明书
