SZG
9854
应用概述 General of applications
★不能承受高温的物料。
★容易氧化的物料。
★对结晶体不允许破坏的物料。
★回收干燥时排除的湿份的物料。
★强烈刺激有毒物料。
★Material that cannot undertake high temperature.
★Material that is easy to oxidize.
★Material that do not permit to destruct.
★To recover material with residual volatile.
★Material with vigorous irritative and toxicity.
设备特点 Features of equipment
★本机将粉末或粒状物料通过真空输送或人工加料到双锥容器中,随着容器的不断旋转,物料在容器中进行复杂的撞击运动,达到均匀的混合。
★本机节约能源、操作方便、劳动强度低、工作效率较高。
★The machine can feed powder or granule into twin cone container through vacuum transmission or manual. With continuous rotation of container, material will make complex impacting motion in the con-tainer and reach to uniform mixing.
★Energy saving, easy to operate, low labor strength, high work efficiency.
项目ltem 规格Specification | 100 | 350 | 500 | 750 | 1000 | 1500 | 2000 | 3000 | 4500 | |
总容量 Total volume | L | 100 | 350 | 500 | 750 | 1000 | 1500 | 2000 | 3000 | 4500 |
工作容积 Working volume | L | 50 | 175 | 250 | 375 | 500 | 750 | 1000 | 1500 | 2250 |
加热面积 Heating area | m2 | 1.16 | 2 | 2.63 | 3.5 | 4.61 | 5.58 | 7.5 | 9.6 | 13.8 |
转速 Rotating speed | rpm | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 4 | 4 |
电机功率 Power | Kw | 0.8 | 1.5 | 1.5 | 2 | 3 | 3 | 4 | 5.5 | 7.5 |
回转高度 Height of frame roating | mm | 1750 | 2100 | 2250 | 2490 | 2800 | 2940 | 2990 | 3490 | 4150 |
罐内设计压力 Designed pressure in contanier | Mpa | -0.1~0.15 | ||||||||
夹层设计压力 Designed pressure in interlayer | Mpa | 0.3 | ||||||||
总重量 Total weight | Kg | 800 | 1100 | 1200 | 1500 | 2800 | 3300 | 3600 | 6400 | 7500 |
所有参数仅作参考,视物料情况,本公司拥有变更权利,并不另行通知。
All datas are used for reference only. According to the condition of material, our factory has the right to change but not notice, pardon
