• HCS60 可编程精密温度控制从室温到60 ℃ , 0.1 ℃精度,可选择较高的温度上限为95
℃
技术参数:
Temperature Range | 5°C to 60°C |
Optional higher temperature limit available | |
Temperature Resolution | 0.01 °C |
Temperature Stability | ±0.1 °C at 37 °C |
Minimum Heating and Cooling Rate | ±0.1 °C per hour |
Maximum Heating Rate | +50 °C per minute at 37 °C |
Maximum Cooling Rate | -50 °C per minute at 37 °C |
Temperature Control Method | PID with Variable Bipolar DC Control |
Temperature Control Sensor | 100 Ω Platinum RTD |
Operating Working Distance | 5.6 mm with optional insert |
Minimum Working Distance | 0 mm |
(with insert removed) | |
Operating Condenser Distance | 19.1 mm |
Sample Area | 35 mm |
Chamber Height | 19 mm |
Sample Viewing Aperture | 13 mm with optional insert |
20 mm |
